* Type: High Capacity Li-ion Rechargeable Battery
* Brand: Sanyo
* Part No.: NCR20700B
* Maximum Size: （D）20.4*（L）70.3mm
* Nominal Voltage: 3.6V
* Nominal Capacity: 4250mAh
* Continuous Maximum Discharge Current: 15A
* Weight: 63g
* Made in Japan
* Brand: Sanyo
* Part No.: NCR20700B
* Maximum Size: （D）20.4*（L）70.3mm
* Nominal Voltage: 3.6V
* Nominal Capacity: 4250mAh
* Continuous Maximum Discharge Current: 15A
* Weight: 63g
* Made in Japan
● Model: NCR20700B
● Nominal Capacity: 4250mAh
● Minimum Capacity: 4050mAh
● Nominal Voltage: 3.6V
● Charging Method: CC-CV
● Charging Voltage: 4.20V
● Standard Charging Current: 2000mA
● Standard Charging Time: 180min.
● Cut Off Voltage: 2.5V
● Continuous Maximum Discharge Current: 15A
● Weight: 63.0g
● Maximum Dimensions: (D)20.4*(L)70.3mm
● Temperature
Charge: +10 to +45° C
Discharge: -20 to +60° C
Storage: -20 to +50° C
● Nominal Capacity: 4250mAh
● Minimum Capacity: 4050mAh
● Nominal Voltage: 3.6V
● Charging Method: CC-CV
● Charging Voltage: 4.20V
● Standard Charging Current: 2000mA
● Standard Charging Time: 180min.
● Cut Off Voltage: 2.5V
● Continuous Maximum Discharge Current: 15A
● Weight: 63.0g
● Maximum Dimensions: (D)20.4*(L)70.3mm
● Temperature
Charge: +10 to +45° C
Discharge: -20 to +60° C
Storage: -20 to +50° C
