Prodcuts > High Capacity Bare Cells > Li-ion 18650 Battery
* Type: High Capacity Li-ion Rechargeable Battery
* Brand: Panasonic
* Part No.: NCR18650BF
* Maximum Size: D-18.20mm, L-65.00mm
* Nominal Voltage: 3.6V
* Nominal Capacity: 3400mAh
* Continuous Maximum Discharge Current: 3250mA
* Weight: 46.5g
* Made in Japan
* Brand: Panasonic
* Part No.: NCR18650BF
* Maximum Size: D-18.20mm, L-65.00mm
* Nominal Voltage: 3.6V
* Nominal Capacity: 3400mAh
* Continuous Maximum Discharge Current: 3250mA
* Weight: 46.5g
* Made in Japan
● Model: NCR18650BF
● Typical Capacity: 3350mAh
● Minimum Capacity: 3250mAh
● Nominal Voltage: 3.6V
● Charging Method: CC-CV
● Charging Voltage: 4.20±0.05V
● Standard Charging Constant Current: 1625mA
● Standard Charging Time: 3.5 hours
● Discharging Cut Off Voltage: 2.5V
● Continuous Standard Discharge Current: 1625mA
● Continuous Maximum Discharge Current: 3250mA
● Weight: 46.5g
● Maximum Dimensions: D-18.20mm, L-65.00mm
● Operating Temperature
Charge: 0 to +45° C
Discharge: -20 to +60° C
● Storage Temperature: -20 to +50° C
● Typical Capacity: 3350mAh
● Minimum Capacity: 3250mAh
● Nominal Voltage: 3.6V
● Charging Method: CC-CV
● Charging Voltage: 4.20±0.05V
● Standard Charging Constant Current: 1625mA
● Standard Charging Time: 3.5 hours
● Discharging Cut Off Voltage: 2.5V
● Continuous Standard Discharge Current: 1625mA
● Continuous Maximum Discharge Current: 3250mA
● Weight: 46.5g
● Maximum Dimensions: D-18.20mm, L-65.00mm
● Operating Temperature
Charge: 0 to +45° C
Discharge: -20 to +60° C
● Storage Temperature: -20 to +50° C
