1.Quality Rechargeable LiFePO4 Cell IFR26700
2.Model: IFR26700
3.Nominal Voltage: 3.2V
4.Nominal Capacity: 4500mAh
5.Made in China
2.Model: IFR26700
3.Nominal Voltage: 3.2V
4.Nominal Capacity: 4500mAh
5.Made in China
1. Type: Cylindrical LFP rechargeable lithium ion battery
2. Dimension
Φ=26.2±0.3mm
H=65.3±0.2mm
3. Nominal Capacity: 4500mAh
Minimum Capacity: 4400mAh
Minimum Capacity: 4400mAh
4. Nominal Voltage: 3.2V
5. Limited Charging Voltage: 3.6V
5. Limited Charging Voltage: 3.6V
6. Recommended Charging Conditions: 0.5C CC/CV, cut off 0.01C
7. Max. Continuous Charging Current: 1C
7. Max. Continuous Charging Current: 1C
8. Max. Continuous Discharge Current: 3C
9. Cycle Life: 1500cycles [Capacity≥80%]
10. Weight: Approximately 90g
11. Internal Resistance: ≤20mΩ
12. Temperature
Charge: 0~+50°C
Discharge: -20~+60°C
Storage: -20~+45°C (3 months)
-10~+25°C (6 months)
-10~+25°C (6 months)
